Jekyll
Build sheet
17 parts
- +5
Frame
Cannondale Jekyll
- Material
- Carbon
- Rear travel
- 165 mm
- Wheel size (current config)
- 29
Suspension
RockShox ZEB Charger 3.1 RC2 Ultimate
- Wheel size
- 29
Fox DHX2 Coil Factory
Drivetrain
- Speeds
- 12
- Actuation type
- Mechanical
- Compatibility
- I-spec EV
- Mount
- I-Spec EV
- Weight
- ~130 g
- Speeds
- 12
- Maximum cog
- 51 t
- Mount type
- Standard hanger
- Cassette compatibility
- Shimano
- Clutch
- Yes
- Weight
- 320 g
- Total capacity
- 45 t
- Speeds
- 12
- Range
- 10-51T
- Freehub body
- Shimano Micro Spline
- Weight
- 595 g
Shimano Deore XT
- Speeds
- 12
- Chainring interface
- BSA
- Spindle / BB interface
- 24mm
- Crank length
- 165 / 170 / 175 mm
- Speeds
- 12
Shimano Deore XT
- Shell standard
- BSA (Threaded)
- Shell width
- 73mm
Wheels & Tires
DT Swiss 350 FR 541
- Wheel size
- 27.5 / 29
- Internal rim width
- 30 mm
- Hub spacing
- 12x157 (Super Boost)
- Wheel size
- 27.5 / 29
- Width
- 2.50 / 2.60
- Compound
- 3C MaxxGrip / Dual / MaxxTerra
- Casing
- DoubleDown / Downhill / EXO / EXO+
- TPI
- 60 TPI
- Tubeless ready
- Yes
- E-bike rating
- true
- Weight
- ~1109 g
Maxxis Minion DHR II DD
- Wheel size
- 27.5
- Width
- 2.5
- Compound
- Maxterra
- Casing
- DoubleDown / Downhill / EXO / EXO+
- TPI
- 60 TPI
- Tubeless ready
- Yes
- E-bike rating
- ~E50
- Weight
- ~1000 g
Brakes
Cockpit
Renthal Alloy stem
- Bar clamp diameter
- 35 mm
- Material
- Aluminum
Seatpost & Saddle
TranzX dropper post
- Weight
- 245 g
Frame geometry
Rider frame size: M · Catalog measurements
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Reach (mm) | 425 | 450 | 475 | 510 |
| Stack (mm) | 625 | 634 | 643 | 652 |
| Head tube angle (deg) | 64 | 64 | 64 | 64 |
| Seat tube angle (deg) | 77.5 | 77.5 | 77.5 | 77.5 |
| Chainstay length (mm) | 430 | 435 | 442 | 450 |
| Wheelbase (mm) | 1193 | 1227 | 1264 | 1311 |
| Head tube length (mm) | 100 | 110 | 120 | 130 |
| Stack-to-reach | 1.47 | 1.41 | 1.35 | 1.28 |
