Tour de France 2026
Tadej Pogačar 🇸🇮Pro rider
Y1Rs
A size-M Y1Rs with a CC.Y1 cockpit and a custom 3D-printed Argo Adaptive saddle.
Build sheet
11 parts
- +2
Frame
Colnago Y1Rs
Rider setup
- Frame size
- M
- Material
- carbon
Wheels & tires
- Tubeless ready
- true
- External rim width
- 30.8 mm
Continental Grand Prix 5000 TT TR
Rider setup
- Nominal width
- 28 mm
- Measured front width
- About 31.6 mm
- Measured rear width
- About 30.8 mm
Drivetrain
Shimano Dura-Ace Di2 R9200
- Chainring interface
- HollowTech 2
- Spindle / BB interface
- Hollowtech II
Rider setup
- Crank length
- 165 mm
Carbon-Ti chainrings
Rider setup
- Tooth combination
- 55/40T
Cassette, model unspecified
Rider setup
- Range
- 11-36T
Bikone BSA Road Ceramic Aero UAE
Cockpit & contact points
Colnago CC.Y1 Gullwing integrated cockpit
Rider setup
- Bar size
- XX-377
Fizik Argo Adaptive
Rider setup
- Customization
- Custom 3D-printed
Frame geometry
Rider frame size: M · Catalog measurements
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Reach (mm) | 368 | 377 | 386 | 395 | 404 |
| Stack (mm) | 495 | 520 | 540 | 565 | 590 |
| Head tube angle (deg) | 70.8 | 71.9 | 73.0 | 73.5 | 73.5 |
| Seat tube angle (deg) | 75.0 | 74.5 | 74.0 | 73.7 | 73.0 |
| Chainstay length (mm) | 408 | 408 | 408 | 408 | 408 |
| BB drop (mm) | 74 | 74 | 72 | 72 | 72 |
| Fork length (mm) | 376.5 | 376.5 | 376.5 | 376.5 | 376.5 |
| Head tube length (mm) | 88.5 | 108.5 | 126.5 | 150.5 | 176.5 |
| Stack-to-reach | 1.35 | 1.38 | 1.40 | 1.43 | 1.46 |
Rider setup
- Reported weight
- 7.07 kg, measured by Colnago
